TECHNICAL SPECIFICATIONS- Rate of Rise cum Fix Temperature type
- Dual LED for 360 degree visibility
- 2 wire based detector visibility
- Advance algorithms provides advanced
- detection discrimination
- Easy installation
- Low maintenance
- High immunity against unwanted alarms
- Stable heat chamber No adjustment or
- replacement required
| Operating Voltage | DC (10.830) V |
| Frequency | 3-5 Seconds |
| Heat Sensitivity | 135 F/ROR |
| Reset Voltage | Less than 1 volt |
| Reset time | Less than 1 sec. |
| Alarm indication | 2 continuous emitting red LEDs |
| Weight | 140 gram with base |
| Start up current | 100 UA |
| Alarm current (Max) | 50 mA |
| Stand by current | 40 UA |
| Dimension | Dia 100mm, ht 46mm |
